Electrical systems – 5000 Parameters T-code 497
Valid from serial number 723984-
Date 2005-11-04
Order number 222996-040
Table 3: Option 3 – Choice of movement Selected movement
Independent variable #3
Fork lowering or driving backward or AOM
26
Fork lowering or driving forward or driving backward or AOM
27
Fork lift or fork lowering or AOM
28
Fork lift or fork lowering or driving forward or AOM
29
Fork lift or fork lowering or driving backward or AOM
30
Fork lift or fork lowering or driving forward or driving backward or AOM
31
Parameter 20 You decide yourself what the hour meter will show. 1A = Key time 2b = Movement time 3c = Drive motor time 4d =Pump motor time 5s = Time for service
Parameter 21 You must specify the type of battery the truck is equipped with. In order to set the meter for the battery’s level of discharge, the following should be taken into account: • Acid concentration when the battery is fully charged, to check the grade of the battery. Must be between 1.27-1.29. • When the lifting capacity is disconnected (the battery is 80 % discharged), the value must be close to, but not below, 1.14. The acid concentration can vary depending on the battery make.
13- 36
