Electrical systems – 5000 Parameters Order number 222996-040
Date 2005-11-04
Valid from serial number 723984-
T-code 497
The parameter symbol is lit (i.e. stops flashing). • Select independent variable #1 by activating the speed control L1. Independent variable value #1 is displayed after 1 second. • Press the horn button S18.
The parameter symbol flashes. • Enter the independent variable value #1 by repeatedly operating the speed control L1 in either direction. See the list of optional functions in Table 2: • Press the S18 horn button once to confirm the new setting.
The parameter symbol is lit (i.e. stops flashing). Adjust independent variables #2, #3 and #4 in the same way as above. • Switch off the truck by pressing
on the keypad.
The optional function is now activated. • Check that the optional function works correctly before the truck is put back in operation.
Table 2: List of configurable optional functions Independent variable #1
Independent variable #2
Independent variable #3
Independent variable #4
Independent variable #0 = 1: The option button controls the spider output 0:Spider 0 1:Spider 1
0:Digital output 1 1:Digital output 2 2: :Digital output 3 3: :Digital output 4
1-6:option button 1-6
Type of function: 0:instantaneous 1:butterfly switch
Independent variable #0 = 2:Reduced running speed controlled by the spider’s digital input 0:Spider 0 1:Spider 1
0-7:Digital input 1-8
0-12:reduced speed 40-100% (i.e. 40+5*arg3 e.g. 4: 40+5*4=60%)
0:high-speed range 1:low-speed range 2: both ranges
Independent variable #0 = 3:Activate the spider output for specific movements 0:Spider 0 1:Spider 1
© TIEE SARL
0:Digital output 1 1:Digital output 2 2: :Digital output 3 3: :Digital output 4
Service Manual
Select movements. See Table 3:
7PLL24
Initial position: 0: shines constantly 1: flashes 1 Hz 2: flashes 2 Hz
13- 33
