Electrical systems – 5000 Parameters T-code 497
Valid from serial number 723984-
Date 2005-11-04
Order number 222996-040
Changing non-configurable options • Ensure the truck is in parameter mode.
The parameter symbol is lit. • Select parameter #15 using [L1]. The first set-up of sub-parameters is displayed The next set-up of sub-parameters is displayed if you continue to activate the speed control L1. Ensure that only the relevant sub-parameters are displayed. The value of the sub-parameters is displayed after 1 second. • Press the horn button S18.
The parameter symbol flashes.
.
• Enter the sub-parameter value by repeatedly operating the speed control L1 in either direction. See Table 1: for more information. • Press the S18 horn button once to confirm the new setting.
The parameter symbol is lit (i.e. stops flashing).
• Switch off the truck by pressing
on the keypad.
The non-configurable option is now activated. • Check that the function works correctly before the truck is put back in operation.
13- 30
Service Manual
7PLL24
