Electrical systems – 5000 Parameters T-code 497
Parameter
Description
20
Valid from serial number 723984-
Date 2005-11-04
Unit
Order number 222996-040
Min .
Max .
Step
Std .
Description
Hour meter option
1
5
1
2
Select hour meter.
21
Battery size
1
20
1
95
Selection of battery size.
22
Inductive sensor
0
1
1
1
0: Mechanical switch 1: Inductive sensor
25
Service interval
0
2000
50
100
Option for setting service timer
28
Lift button selection
1
3
1
1
Button selection
39
Password
1
12
1
1
States which level of authorization the driver has for the parameters. Odd values specify open driver parameters, even values specify that driver parameters must be opened using the CAN key
1h
13.6.4 Parameter description Parameter 10 NOTE! The functionality of parameter #10 is set aside if the value of parameter #39 is set to 5,6,7 or 8. The PIN codes are managed using the socalled expanded keypad. See section “Expanded keypad - General” on page 41 for more detailed information.
Ten drivers can have their own PIN code to gain access to the truck. Each driver can set all driver parameters individually. On delivery the PIN code is set to 1 and this only applies for driver no. 1. Code 0 is not accepted as a solitary code. When you wish to start the truck enter your code and press the green button numbered 1. When you want to switch off the truck, press the red button numbered 0. When the CAN key is connected, you can start the truck by simply pressing the green button numbered 1. Switch off by pressing the red button numbered 0.
Parameter 14 Specifies the speed you will have when you reach the first speed sensor.
Parameter 15 - Non-configurable option See “Option parameters” on page 29. 13- 28
