SYSTEM / Electrical System Headlight Lighting Circuit
• When the key switch is turned to the ON position, terminal B is connected to terminal ACC in the key switch. • Current from terminal ACC is supplied to the headlight switch through fuse #12 in fuse box. • When the headlight switch is positioned at Headlight, power lights each clearance light. (Refer to Clearance Light Lighting Circuit.) Power from terminal #2 in the headlight switch is supplied to the dimmer switch. • When the dimmer switch is set to Low (low beam), power is divided and supplied to fuse #1 and fuse #2 in fuse box. • Power from fuse #1 in the fuse box lights the low beam of right headlight. • Power from fuse #2 in the fuse box lights the low beam of left headlight. • When the dimmer switch is set to High (high beam), power lights the high beam of head lights through fuse #3 in fuse box. • Another power is supplied to terminal 1B-22 in the monitor unit and lights the high beam indicator in it.
T2-3-23
