SYSTEM / Electrical System HEADLIGHT CIRCUIT Clearance Light Lighting Circuit • When the key switch is turned to the ON position, terminal B is connected to terminal ACC in the key switch. • Current from terminal ACC is supplied to the headlight switch through fuse #12 in fuse box. • When the headlight switch is positioned at the Clearance Light, one of power from terminal (1) in the headlight switch is supplied to terminal 1B-21 in the monitor unit and the clearance light indicator lights. • Another power to fuse box is divided and supplied to fuse #4 and fuse #5. Power from fuse #4 lights the left front clearance light, right rear clearance light, and license-palte light. Power from fuse #5 lights the right front clearance light and left rear clearance light.
