SYSTEM / Electrical System ENGINE STOP CIRCUIT • Current from terminal BR is supplied to the engine
• When the key switch is changed ON into OFF,
stop solenoid holding side through fuse #8 in fuse box with the key switch ON so that the plunger of the engine stop solenoid is held.
current from terminal BR is not supplied and the plunger of the engine stop solenoid is not held so that the control rack is pushed by the spring force and the engine is stopped. • In addition, current is not supplied to the fuel pump and it is stopped.
Fuse Box
Key Switch B
R1 R2 BR ACC C
HEAT OFF ON START
Battery Power
8
Fuel Pump
Engine
Engine Stop Solenoid
Holding Side
T4FG-02-03-009
NOTE: The illustration shows the current flow when the key switch is in the ON position.
