SYSTEM / Electrical System REVERSE LIGHT / BUZZER CIRCUIT When Forward/Reverse lever is operated • When the key switch is turned to the ON position, power from terminal ACC is supplied to parking brake relay [2] through fuse #7 in the fuse box. • Current through parking brake relay [2] is supplied to the forward/reverse lever through parking brake relay [1]. • When the forward/reverse lever is set to the reverse position, battery power is divided and one of power is supplied to the reverse light and the reverse buzzer. • Another power is supplied to the reverse side of forward/reverse selection solenoid valve in the HST pump so that the signal is sent to the HST control unit and [R] on the forward/reverse and shift position indicator on the monitor LCD is displayed.
T2-3-33
