Equipment Inside the Cab Lighter
Controls
[NOTICE] ◆ Observe the following precautions to prevent a fault in the electrical system: • Do not let the lighter remain pushed in. • Pull out the lighter by hand if it does not pop out within 15 to 20 seconds after it has been pushed in. • Do not use power receptacle for anything other than a lighter. • Do not allow the lighter to become deformed. A misshapen lighter will fail to come out. Replace a lighter that is malfunctioning.
1
2 3
5
The lighter will pop out a few seconds after it has been pushed in. Pull out to use.
4 T21636
1. Lighter 2. Defroster switch (option) 3. Ashtray 4. Fan switch (option) 5. Cab lamp switch
24V
Equipment Inside the Cab Ashtray
T00336
Close the lid after use. To clean, lift out the entire unit.
Cab Lamp Switch "DOOR" ・・・lamp turns on when the door is open and goes off when the door is closed "OFF" ・・・・・lamp stays off regardless of door position. "O N " ・・・・・lamp stays on regardless of door position.
T00335
(DOOR) (OFF)
(ON ) T00727
