Steering Steering Modes
Controls
2
(1)Two-wheel steering mode Steering is performed by the two front axle wheels only. Use this steering mode to travel on public roads. (2)Four-wheel coordinated steering mode The front wheels and rear wheels turn in opposite directions. This steering mode is useful in a small work site, because it provides the smallest turning radius. (3)Crab steering mode The front wheels and rear wheels turn in the same direction. This steering mode is useful to pull the vehicle over to the side of a road, because the vehicle travels obliquely.
1
T21638
1. Steering wheel 2. Steering mode select switch
Changing Steering Mode WARNING Two-wheel steering
Traveling on public roads in one of the special steering modes (four-wheel coordinated steering and crab steering) is dangerous. On public roads, never use special steering modes. Use special steering modes at low speeds and within work sites or rough terrain only. On public roads, travel in the two-wheel steering mode.
Four-wheel coordinated steering
Crab steering
T00705E
From Two-wheel to Four-wheel Coordinated/Crab Steering Mode
1. Stop the vehicle with the front wheels centered. ◆If the steering mode is changed with the front wheels turned even slightly, the steering angle will be different between the front wheels and rear wheels.
Choose from three steering modes using the steering mode select switch. The crane travels differently in each steering mode. Choose the steering mode best suited to the situation.
T00706
STEERING SELECT T02938
Steering
