T012032E
Starting and Stopping the Engine "START" ・・・Starts the engine. Release the key after the engine has started. The switch will automatically return to ON. "BATT" ・・・・The fan, washer, wiper, horn, and working
Controls 1
lamps can be used with the engine off. "HEAT" ・・・・Energizes the engine preheating circuit. Use this position to start the engine in cold weather. Releasing the key automatically returns the switch to BATT.
2
Pre-starting Checks Before starting the engine, perform the following inspection and checks:
3 T21642
1. Perform the pre-operational inspections.
1. Starter switch 2. Fuel control knob 3. Accelerator pedal
◆For an explanation of the engine pre-operational inspection procedure, see the "Engine Operation and Maintenance Manual".
How to Use the Starter Switch
2. Make sure that the controls are placed in the following positions: (1) Hoist, boom telescoping, boom elevating and swing control levers ・・・・・・・・・・・・・・・・・・・・・・・Neutral (2) Parking brake switch ・・・・・・・・・・・・・・・・・"PARK" (3) Gearshift lever ・・・・・・・・・・・・・・・・・・・・・・・・・"N" (4) PTO switch ・・・・・・・・・・・・・・・・・・・・・・・・・"OFF"
[NOTICE] ◆ Do not leave the starter key in the “ON” position with the engine stopped. The battery will run down if the working lamps, fan, or other equipment is used for hours with the engine off and the starter switch turned to BATT or ON. If using electrical equipment for long periods of time, be sure to run the engine to maintain the battery charge.
BATT
OFF
ON
HEAT
START
T00689
"OFF" ・・・・・Shuts off the engine. The key can be inserted or removed in this position. Turning the switch back to OFF shuts off the engine. "ON" ・・・・・・All electrical systems are activated.
Starting and Stopping the Engine
27
Starting and Stopping the Engine
