How to Read the Instrument Panel Meters and Gauges 1
2
3
4
5
6
T21643
1. Torque converter oil temperature gauge 2. Water temperature gauge 3. Speedometer
4. Tachometer 5. Air pressure gauge 6. Fuel gauge
Torque Converter Oil Temperature Gauge
Water Temperature Gauge
[NOTICE] ◆ When the gauge needle reaches the yellow zone, decrease load and travel while paying attention to the oil pressure. When the needle reaches the red zone, oil temperature is too high. Stop the vehicle in a safe location and idle the engine to lower the oil temperature.
[NOTICE] ◆ The engine may overheat if the gauge needle reaches the red zone. Stop the vehicle in a safe place and idle the engine to lower the water temperature. However, if the radiator fan is not running, stop the engine immediately. After the engine has cooled down, examine and locate the cause of trouble.
This gauge indicates the temperature of the torque converter oil. When traveling, the needle should be in the green zone.
Green
This gauge indicates the temperature of the engine cooling water. When traveling, the gauge needle should be in the green or white zone.
Yellow Red
Green Red
White
VERTER CON OIL TEMP
ER TEM P WAT
T00679E T00680E
