Crane Operator’s Cab Locking and Unlocking
Opening and Closing the Door
Insert the door key in the lock, and rotate it clockwise to lock the door, or counterclockwise to unlock it. ◆Do not leave the crane with the key inserted in the lock. ◆The door will lock if closed with the lock knob pushed in and the door handle pulled upwards. Do not leave the key in the cab or you will be locked out!
WARNING The door, if not completely shut, could open when the vehicle is traveling. Before traveling, be sure to close and lock the door.
CAUTION Do not attempt to shut the door, holding it at the end. Your fingers may be pinched. When shutting the door, hold the door handle.
Leaving the Door Held Open To keep the door open during crane operation, and press the lock lever forward with the door fully open. Before closing the door, press the lock lever to the rear.
Outer handle
Lock lever
Door Lock T21170E
T00671E
Lock knob
Inner handle
T02992E
From Outside the Cab Pull the outer handle sideways to slide the door open or shut.
From Inside the Cab Pull the inner handle sideways to slide the door open or closed. ◆The door will be locked after the door is closed and the lock knob is pushed in. The door lock will be released by pulling up the lock knob.
Crane Operator’s Cab
