T013792E
Air Dryer Function Check ・・・・・・・・・・・・Every 250 Hours or Every 3 Months Air Dryer Desiccating Agent Replacement ・・・・・・・・・・・Every 1,000 Hours or Once a Year
Parking Brake Pad Clearance Adjustment ・・・・・・・・・・ Every 1,000 Hours or Once a Year WARNING The parking brake pads come to use limit when their remaining thickness becomes as small as 0.15 in. (3.8 mm) at any point on the circumference. They must be replaced with new ones, then. After parking brake has been used as emergency brake, the pads stay remarkably worn out. Check them soon. If you fail to check the pads for wear after such brake application, the pad wear may cause system failure.
[NOTICE] ◆ If the compressor air dryer performance is poor, vapor contained in the compressed air will condense into water, adversely affecting the equipment. Regularly check and replace the desiccating agent. ◆The air dryer is installed near the rear of the air tank (right side of the carrier). Air dryer
1. Release parking brake to bring the brake chamber into the extension side stroke end.
Brake chamber Jam nut Link
Hand brake bolt Disk plate
T002874E
Front axle
Performance Inspection Open the drain cock on the air tank and check whether any water drains out. If drainage occurs during normal operation, the desiccating agent may have become permeated with oil, etc., lowering its ability to absorb moisture. If so, have the nearest TADANO distributor or dealer check the air dryer.
T20930E
2. Screw the hand brake bolt in accordance with the pad wear, until the clearance between the pad and the disk plate becomes approx. 0.006 in. (0.15 mm) per side.
Desiccating Agent Replacement Disk plate
For replacement of the desiccating agent, contact the nearest TADANO distributor or dealer.
Lever
Brake System
160
Pad 0.006in. （0.15mm）
T21179E
Brake System
