T012262E
Stowing the Single Top
5. Reeve the auxiliary winch wire rope through the rope arresters.
WARNING When working at an elevated position, use a platform or scissor lift to prevent falling and ensure safety. Stow the single top securely. Use the attached bolts, cotter pins and rings to ensure that the stowing pin, connecting pins, rope guide pins, and hook mounting pins do not slip out of position.
Auxiliary winch wire rope
Rope arresters
Anchor
1. Stow the auxiliary hook block in its stowing position.
T20923E
2. Take the rope socket out from the auxiliary hook
6. Attach the rope socket to the anchor on the jib.
block.
Lock pin
Rope socket
Rope socket
Auxiliary hook block T00510E
T03017E
7. Wind the auxiliary winch wire rope, leaving it slightly
3. Lower the boom all the way down.
slack. [NOTICE] ◆ Operate the auxiliary winch carefully. If the wire rope is wound too tight, the anchor will be broken.
4. Remove the weight for the anti two block device and remove the auxiliary winch wire rope from the sheaves of the boom head and single top. ◆Place the rope guide pin on the original position.
8. Connect and disconnect the leads of the anti two block device as shown.
Rope guide pin
T03019E T00514
T03019E
Single Top
113
Single Top
