Traveling with a Load Lifted WARNING Do not travel at a speed exceeding 1 mph (1.6 km/h). Do not lift the load high. Keep it near the ground. For safety do not fail to hold it with an auxiliary rope. Do not shift into “D” or “2” position, but keep the gearshift lever positioned at “1”. Avoid abrupt motion: start, stop and steering. Otherwise the lifted load is given oscillation. Do not operate the crane while traveling. Before traveling, extend the outrigger beams and extend the jacks until the outrigger floats are slightly clear of the ground. [NOTICE] ◆ Do not travel with the PTO switch set OFF and with a load on.
1. Register “On rubber creep operation” on the load moment indicator.
×1000lbs
ft
MAX ×1000lbs
ft
T02915
2. Set the drive mode select switch to “4-WHEEL (Lo)”.
3. Perform steps 1 and 2 of the “Stationary”. 4. Set the swing brake switch to ON and apply swing brake. Set the swing lock lever to “LOCK” and insert the swing lock pin.
5. Set the parking brake switch to OFF and start to travel slowly.
