Stowing the Outriggers
1. Flick the jack/slider selector switch to the JACK position. Keeping the extend/retract selector switch pressed to the RET. position, press the collective control button and retract the jack cylinders fully.
WARNING If the outriggers are retracted with the boom extended, the crane may overturn. Fully retract the boom and stow in the traveling configuration before retracting the outriggers. Traveling with the crane without first securing the retracted outriggers with the lock pins is dangerous. The outrigger beams could accidentally extend during travel. Be sure to securely pin the outrigger beams whenever they are stowed. Unless the gearshift lever is set to other than the “N” position, neither extension nor retraction of outriggers can be performed. Make sure of the gearshift lever “N” position, beforehand.
OUTRIGGER EXT.
CONTROL RIGHT FRONT
RIGHT REAR
LEFT FRONT
LEFT REAR
N RET. SLIDER
ALL
N JACK
T02908
2. Remove all four lock pins.
[NOTICE] ◆ After outriggers’ extension and retraction, set the following switches to neutral: • Extend/retract selector switch • Slider/jack selector switch Unless the extend/retract selector switch is situated at neutral, the outrigger switch non-neutral position lamp flashes.
Lock pin
T02909E
3. Flick the jack/slider selector switch to the SLIDER position. Keeping the extend/retract selector switch pressed to the RET. position, press the collective control button to retract the outrigger beams fully.
O/R SW
T101122
OUTRIGGER EXT.
CONTROL RIGHT FRONT
RIGHT REAR
LEFT FRONT
LEFT REAR
N RET. SLIDER
ALL
N JACK
T02910
Outriggers
