Load Moment Indicator Preoperational Inspection
Before starting operation, check the load moment indicator system according to the instructions given on the "Load Moment Indicator Check" plate.
WARNING Operating the crane with a malfunctioning load moment indicator could cause the crane to overturn or be damaged. Do not operate the crane. Be sure to perform the pre-operational inspection on the load moment indicator system and start the crane only after ensuring that the system is operating properly. Load moment indicator check plate
1. Arrange the crane in the way as follows:
3. Press the set key. On the moment display a mes-
(1) Extend the outriggers to middle or fully. And install the crane level. (2) Stow the jib or the single top. (3) Stow the auxiliary hook. (4) Mount a 1,100 lbs (50 t) hook.
sage will appear as follows: Boom L 34.8 ± 0.3 ft
4. Retract the boom fully. 5. Read out the boom length value and make sure the
2. Press in the check key to make sure:
displayed value is within the standard in above step 3. ◆If the value obtained is not within the standard value, have your machine checked and repaired at your nearest TADANO distributor or dealer.
(1) all the segments on the display panel 1 and 2 and on the moment display light; (2) all the lamps on the control light; (3) the buzzer sounds continuously; and (4) hoisting up, boom extension, and boom lowering operation become impossible.
Load Moment Indicator (AML-L)
