T025052E
Selecting Operational Status
◆(Applicable to the machines with the serial No. 540258 and upward.) After selecting the intended outrigger status, press the register key to register the status. The following symbols will stop flashing and become marked up: • Segment(s) of the moment display • Outrigger state indicative symbol that has been shown up before the register key is pressed (If the “on-rubber” state indicative symbol has been shown up, it will not change.) ◆The outrigger status automatically changes to a onrubber stationary status, when an operation is made for stowing the outriggers after the registration of the outrigger status. Be sure to again register the outrigger status, when necessary.
WARNING Should the operational status be incorrectly selected, the crane might overturn or be damaged, leading to a serious accident. Prior to every operation, check that the selected status corresponds to the actual status of the crane.
Selecting Outrigger Status ◆The "on-rubber stationary" status is the default status and is automatically selected when the power supply is turned on (the PTO switch is placed in the "ON" position). ◆Turning the power off (PTO switch: OFF) automatically erases all the previous settings stored in memory after approximately 2 hours. To resume the operation more than 2 hours after the power has been last turned off, enter the settings all over again. Register the outrigger state by either right outrigger mode select key or left outrigger select key, as follows: (1) When outriggers are extended Press either right outrigger mode select key or left outrigger select key. The outrigger state indicative symbol flashes in accordance with the state that load moment indicator detects on. Make sure this conforms to the actual crane conditions. If it does, press the set key for registration. If the outrigger state indicative symbol change to continuous lighting, this means correct registration of this state. (2) When outriggers are not extended Press on the on-rubber mode select key to make display the on-rubber state indicative symbol to show up. Registration will be made automatically without pressing the registration key.
Register key Right outrigger Left outrigger mode select key mode select key On-rubber mode select key T50098E-1
Fully extended
Mid extended
Mid extended
T20911E
On rubber creep operation
On rubber stationary operation
T02891E
Load Moment Indicator (AML-L)
70
Load Moment Indicator (AML-L)
