Lubrication Oil Engine oil Refer Table A for oil specifications. Recommended Oils If the engine / tractor is not operated for longer time, there are possibilities oil deterioration can occur. Hence, it is recommended to change the engine oil after every year if the tractor / engine is idle or operated less frequently.
1. Mahindra Part No.MCJ15W40 2. Mahindra Part No. MFSHD5W30 3. Mahindra M-Star Ultra Plus Transmission, Hydraulics and Oil Immersed Brakes Use specific Tractor Transmission Fluids which are recommended for oil immersed brake application. Following oils are recommended for optimal performance 1. Warren THF Purple
Further, in long idle condition lack of lubrication can occur. Hence, it is suggested to check oil level before start, top-up 200 to 300 ml of oil, run the engine at low rpm for 5 min. and then start normal operation. This will allow the oil to lubricate all the engine parts optimally.
2. m-UTTO 2 Check with Mahindra service engineer for suitability of any other oils before using. For implements / loader attachments, use only the recommended oils. Do not mix different brand of oils as it may cause performance deterioration especially at lower ambient temperature. Factory filled oil is m-UTTO 2 Chassis Lubricant (CL) Lithium or Lithium complex type grease with Extreme Pressure (EP) additive is recommended. Depending on the expected ambient temperature range during the operation, use grease as mentioned below. For Temperature up to 5°F
Mineral grease NLGI 2 grade
For Temperature below 5°F
Synthetic grease NLGI 2 grade
Front Axle Use gear oil complying to API GL5, MIL-L-2105D specifications. Please refer oil specification chart for oil viscosity grade at different range of ambient temperature.
Oil Specifications Chart (Table A) Sr.
Application
No.
Capacity
Ambient Temperature
Gallon / Quarts
up to 50F
below 5°F and up to –13°F
2.25 / 8.98
API CJ-4, SAE 15W-40
API CJ-4, SAE 5W-30
1.
Crankcase
2.
Transmission & 14.52 / 58.12 Hydraulics
3.
Lubrication Fittings
As required
Mineral grease NLGI 2 grade
Synthetic grease NLGI 2 grade
4.
Front Axle
1.48 / 5.92
GL-5, SAE 80W-90
GL-5, SAE 75W-90
6065 / 6075 2WD & 4WD Open Station Rev 01
SAE 80W - Tractor Transmission Hydraulic Oil
91
