Hydraulics, Transmission & Brake Pedal Free Play Hydraulic and Transmission Strainer Clean suction strainer during every oil change. The suction strainer is located inside the rear housing and can be removed as follows:
D
1) Remove the end cover plate (C) by unscrewing three bolts (B). 2) Pull the suction strainer out from housing. 3) Clean the strainer in clean diesel fuel, using a soft brush, then blow dry with compressed air. 4) Refit the strainer. 5) Refit the cover plate and suction filter. For Service / Replacement of strainer contact your Mahindra Dealer. B C Transmission Oil Drain Transmission oil can be drained from the 4 drain plugs (D), 1 each on speed housing and rear housing and 2 on rear axle housings.
D
Check and Adjust Brake Pedal Free Play Measure free play of pedal stroke (A). Ensure free play is within specified limits. If free play is not within specified limits, adjust brake linkage by rotating turn buckle (B). NOTE: Free play of brake pedal should be between 1 in (25 mm) to 1.2 in (30 mm).
A
B
6065 / 6075 2WD & 4WD Open Station Rev 01
87
