Electrical System Charging Circuit Should the battery be in a low state of charge, which will be shown by lack of power when starting and poor lights and may be due to either alternator not charging or giving lower intermittent output, then proceed as below :
Check Battery Charging Indicator when the engine is running steadily at working speed.
If the Battery Charging Indicator glows, have the equipment checked by your Mahindra tractor Dealer.
Inspect alternator drive belt and adjust as necessary.
Examine the charging and field circuit wiring, tighten any loose connections, replace any broken cables, pay particular attention to the connections.
Starter Motor Removal 1. Disconnect the earth cable from the battery, battery to starter solenoid coil cable, key switch to solenoid coil cable.
To avoid damage to alternator charging system, service precautions should be observed as follows, 1. Never make or break any of the charging circuit connections, including the battery when engine is running. 2. Never short any of the charging compo-nents to ground. 3. Do not use a jumper battery of higher than 12 volt. Always disconnect the battery ground cable before carrying out arc welding on the tractor or any implement attached to the tractor. Use only specified cable for replacement.
2. Remove the mounting bolts and withdraw the starter motor. To install the starter motor, reverse the above procedure. The starter motor should be removed, and a replacement motor or drive end bracket be fitted, a check must be made of the out of mesh clearance after assembling the starter motor to the engine. The dimension between the leading edge of the pinion and the engine flywheel should be no less than 0.125" (3.17 mm).
