Lubrication System Oil Level Check Check engine oil before starting the engine. 1. Remove dipstick gauge (A) provided on the right hand side of the crankcase. 2. Oil level should be between the two marks provided on the dipstick. Oil Change Change Engine Oil as per Routine Service Schedule given in this Manual. 1. Ensure that the engine is stopped before changing oil. 2. Remove the drain plug provided at bottom of oil sump. 3. Allow the oil to drain completely. 4. Now reinstall the drain plug (B). Service the oil filter as explained below. 5. Remove the oil filler cap (C) in the front cover to expose the oil filler neck. 6. Refill the oil sump slowly by recommended grade of oil. 7. Clean and place the oil filler cap again. Engine Oil Filter The life of engine and turbocharger depends upon clean oil being circulated to its bearings. In the normal course of engine operation the lubricating oil undergoes changes which produce harmful by-products. The purpose of the oil filter is to separate and remove dirt and other injurious foreign materials from the oil and prevent these from being circulated in the engine. The Engine oil filter should be replaced as per Routine Service Schedule given in this Manual or whenever engine oil is changed. Changing Spin On Filter 1. Ensure that engine is stopped before changing filter. 2. Remove the lub oil filter Guard. 3. Unscrew the oil filter. 4. Prime the new spin-on filter with clean oil. 5. Screw the new filter to the adapter. 6. Move the Hand and foot throttle to engine "Idle" position. 7. Start the engine, check the oil pressure to see whether the lubricating oil is circulating through the engine. 8. Inspect the oil filter for oil leaks. NOTE : Stop the engine immediately if Oil pressure is not recorded within 10 seconds of engine starting or Leakage is observed. Get the cause identified and rectified before proceeding further. Turbocharger Check the turbocharger periodically as follows. 1. Move the Hand and foot throttle to low engine "Idle" position. 2. Inspect the oil filter for oil leaks through oil supply and drain line. 3. Stop the engine immediately if leakage or abnormal sound is observed. Get the cause identified and rectified before proceeding further.
6065 / 6075 2WD & 4WD Open Station Rev 01
Never allow to let the oil level drop below the ‘Lower’ mark. Add only recommended grade of oil.
A
B
C
Do not drain the oil when the engine is hot. Wait for the engine to cool. NOTE: Engine oil and filter element must be changed after initial 50 hrs. of operation in new tractor or whenever major overhaul of engine is carried out and subsequently after every 500 hrs. or 1 year, whichever is earlier. To avoid delays, we recommend that you carry extra filter elements on hand so that replacements can be made at the correct time. The FILTER is located on the right-hand side of the crankcase. Filling oil takes time. Allow sufficient time for the oil to settle down in crankcase. Dispose of the used oil properly. 81
