Cooling System Water Pump The water pump is equipped with a sealed bearing. Adjusting or greasing will not be necessary. Hose Connections Check periodically to ensure all the connections are in good order and the clips are tight. A leaking connection results in loss of coolant and thus engine efficiency. When using antifreeze in the cooling system, it is absolutely essential to have efficient connection so check these and should there be any doubt as to their serviceability, renew.
C
D
B A
Fan & Fan Belts A plastic fan is mounted on water pump and is driven vide fan belt by the main drive pulley. While the engine is in operation, the fan sucks air through the radiator core. Slippage of belt on pulley can cause over heating. The Fan belts shall always be dry and free from oil or Grease. Incorrect belt tension results in its rapid wear. Main drive pulley is assembled on a roller bearing mounted shaft. Grease nipple is provided on front cover to grease the bearings. Grease the bearings every 600 hrs. of operation. Belt Adjustment To adjust belt tension, loosen the alternator on the adjustable bracket and lock the bolt in the location that gives correct belt tension (270-320 N) such that the belt can be depressed without much effort by the thumb, 0.25 to 0.4 inch.
A. Alternator Mounting B. Alternator C. Adjusting Nut D. Adjusting Bracket
Belt Removal 1. Loosen the Nut (C). 2. Push the alternator down. 3. Ease the fan belt off the alternator pulley. 4. Ease the fan belt off the main drive pulley. 5. Slide out the belt from water pump pulley over the fan blades. Belt Replacement Reverse the procedure of fan belt removal stated above. Adjust the fan belt tension as previously detailed.
NOTE: Under normal conditions use Lithium based NLGI-2 grease with EP additives. Contact your Mahindra dealer for grade of grease to be used under extreme ambient conditions. 6065 / 6075 2WD & 4WD Open Station Rev 01
