Position Control - Operation Quadrant Assembly This system incorporates a Position control and a Draft control. Both these controls are within easy reach of the operator. The operator must be thoroughly acquainted with the location and use of all controls regardless of experience, must read this section carefully before attempting to operate the tractor. Position Control This lever (D) controls the lifting and lowering of all implements used on the three point linkage. 1. Moving the lever Forward will lower the implement. 2. Moving the lever Rearward will raise the implement. B
The control can also be set by PC stop screw (C) to govern the height of out-of-ground implements such as mowers, rakes etc., so that the implement can be lowered to exactly the same height at the commencement of each turn.
A C
PC lever (D) should be used for the following applications: 1. TRANSPORT of implements and turn around at the end of the field. 2. CONSTANT DEPTH of implements on level terrain and for non-ground engaging implements such as spreaders or sprayers. Place the PC lever at desired depth.
D
Tractor Front
Setting of Position Control 1. Move the DC lever (A) to its forward most position. 2. Move the PC lever (D) back to the upper limit and allow the implement to lift fully. 3. Move the PC lever (D) forward until the implement has reached the desired working height. C
4. Set the position control stop screw (C) against the PC lever and tighten the knob.
D
Whenever the PC lever is returned to the front position till the stopper, the implement will return to the same preset height.
B A
Tractor Front
