Controls Opening the Hood The hood is hinged at the rear side and opens away from the operator as follows, 1. Pull the lever (A). The hood will unlock. 2. Lift the hood upwards by hand. Two gas springs (B) provided inside will assist in minimising the effort for lifting. 3. The bonnet strap (C) provided on the bonnet will help the hood to stop at desired angle.
A
4. The mounting of the bonnet strap on the radiator bracket can be removed to open the bonnet fully.
Closing the Hood 1. Ensure the bonnet strap (C) is mounted on both the ends on the tractor. 2. Pull and press the hood downwards until it locks.
C B
50
6065 / 6075 2WD & 4WD Open Station Rev 01
