Controls Hand Throttle Operation Use the Hand Throttle Lever to set a constant engine speed for stationary operation or for field operation wherever desired. Increasing Engine Speed : Pull throttle lever towards operator as indicated in the sticker on the dashboard. Engine Tachometer Speeds : a. Low Idle speed 850 ± 50 rpm b. Rated engine speed 2100 rpm c. High Idle speed 2300 rpm ± 50 rpm Decreasing Engine Speed : Push throttle lever away from the operator as indicated in the sticker on the dashboard Constant Speed Setting : Certain operations may require a particular engine speed. This can be achieved by resting the Hand Throttle Lever in a position where you get the desired engine speed.
Foot Throttle Operation When tractor operation requires repeated speed change, use the foot throttle pedal to temporarily increase engine speed above hand throttle setting. We recommend to keep the hand throttle at minimum and use foot throttle when driving on highway. a. Set the hand throttle lever at desired rpm. b. Depress foot throttle pedal to Increase Engine rpm. c. Release foot throttle pedal to decrease Engine rpm to achieve the previous engine speed set by hand throttle lever.
4WD Engagement Lever This lever is located on L.H side of operator’s seat. It is used to engage or disengage the drive to front wheels and is recommended to be done with tractor in stand still condition. 1. Depress clutch pedal and stop the tractor motion completely. 2. Lift the lever upwards to engage the drive to front wheels. 3. Press the lever downwards to disengage the drive.
Do not engage or disengage the 4WD lever while the tractor is in motion. 44
