Switches 3. Plough Lamp Switch (C) This is a 2-way rotary switch located on the LH side of the scuttle extension cover. 1. Off 2. Illuminates Plough Lamp C
4. Hazard Switch (D) This is push type switch located bottom side of Steering column cover. The operations are as follows. On Position - Operates left and right turn signal lamp simultaneously. This operation can be performed even if the key switch is in OFF position. D
5. Brake Switch The function of this switch is to automatically turn on the stop lamp when the brake pedal is pressed. 6. Forward Reverse Switch (E) This is a 3 way lever switch. It operates by lifting the lever then up and down direction and the operations are as follows. Center
:
Neutral position.
Forward
:
Vehicle move in forward direction.
Rearward
:
Vehicle move in reverse direction.
E
1. Moving the lever up and down without lifting, can damage the switch. 2. Don’t hold the lever while getting on or off the tractor.
