Instrument Cluster PTO Indicator This is Amber color indication for PTO. This indicates when PTO is ON position. Parking Brake Indicator This is a Red LED and glows when the Parking Brake is applied.
MIL Indicator This indicator will glow when the starter switch is turned to “ON” position. This indicator will turn-off after engine is CRANKED.
The park brake should not be used for more than 1 hours with ignition on condition as this will result in damage of brake lamps.
A malfunction in the electronic emission control system (ECU) is indicated by a continuously “GLOWING” or “BLINKING” Indicator, even past CRANKING of the engine. In such an event, get the problem rectified by an authorized Mahindra Dealer. Battery Charging Indicator This is a Red LED and glows when the battery is not getting charged. Also this LED will glow during ignition ON and should go OFF immediately after engine rpm reaches 800 rpm.
Low Oil Pressure Indicator This is a Red LED and glows when the engine is operating at Low oil pressure. & also to warn the operator, a beeper will also give an audio warning.
During engine running, if this LED glows it means Battery is not getting charged. A beeper will also give an audio warning in such case.
This indicator will also glow when the Key is in ON position before starting the engine and continue to glow till engine oil pressure builds up after starting the engine.
Continued operation of engine despite the low oil pressure indicator glowing may lead to engine seizure.
Beeper Output Provision The Beeper will beep at different rate during following conditions. Description
Beeps/min
High Coolant Temperature
60
Engine Low Oil Pressure
40
Low Battery Charge
30
Low Fuel
15
Air Filter Clog
10
