Instrument Cluster Service Reminder Indicator This is an amber color LED and glows continuously when the service of tractor is due. This function is set for first 50th hour and 500, 900, 1300, 1700 hrs ... of engine running. The operator is thus indicated for General Service Due. Resetting can be done by authorized Mahindra Dealer as soon as the general service is done. Coolant Temperature Gauge The temperature gauge is displayed on the right side of instrument panel when viewed from the driver’s seat. This gauge indicates coolant temperature of the engine. When the pointer lies in RED band: 1. Indicates the engine coolant temperature is going to exceed the limit. 2. Identify the cause by running the engine at low idle rpm for some time before switching OFF. 3. Further engine operation should be done only after elimination of the problem. Graduation
Temperature (0F)
C
104
1
105.8 - 122
2
131
3
132.8 - 167
4
168.8 - 215.6
5
222.8 - 224.6
6
226.4
7
226.4 - 228.2
H
231.8 - 248
High temperature indication will blink (30 cycles / min) at 228.20 F and switch off at 226.40 F. High temperature Buzzer will give 60 beep / min at 228.20 F and switch off at 226.40 F. Cold Start Device Indicator When the key is turned to 2nd position, the cold start indicator glows to indicate the activation of heater element provided in engine’s intake elbow. The indicator continues to glow for approx. 45 seconds. A timer controls this time. 1. Turn the key to "ON" position and wait till the heater indicator is goes-off. 2. Crank the engine when the heater indicator light is off
36
6065 / 6075 2WD & 4WD Open Station Rev 01
