Instrument Cluster Engine Coolant Temperature Warning Indicator This is a Red LED and is located on top of tachometer. It will glow continuously when temperature of coolant rises above 228.20 F. The pointer of Temperature gauge will lie in the RED band under such condition. Also to warn the operator, A beeper will also give an audio warning. (60 beeps / Min) Air Filter Clogging Indicator
Continued operation of engine despite the high temperature warning indicator glowing may lead to engine seizure.
This is an Amber LED and glows when Air filter is clogged. This gives an indication to the customer that the air filter needs to be cleaned for proper functioning. Check Engine Indicator This indicator will glow when the starter switch is turned to "ON" position. This indicator will turn-off after engine is CRANKED. A malfunction other than Emission, such as Sensor failures would be indicated by a continuously "GLOWING" or "BLINKING" Indicator, even past CRANKING of the engine. In such an event, get the problem rectified by an authorized Mahindra Dealer. High Beam Indicator This is a Blue LED and glows when Head Lamps are operated in High Beam. Clutch Over Ride Indicator Optional feature: This is an Amber LED & Glows when clutch Pedal is pressed for more than 10 sec. This symbol will be glowing if the feature is equipped. F-R Shuttle Neutral Indicator This is a Green LED and glows when the F-R shuttle shift lever is not in neutral position. Fuel Gauge The Fuel Gauge is displayed on the left side of rpm meter when viewed from the driver’s seat. It indicates quantity of fuel available in the fuel tank. The indication is divided into 9 stages. The Red zone indicates that the fuel level is less and the tractor should be refueled for uninterrupted run. Graduation
Gallons / Liters
E
3.43 / 13
1
5.55 / 21
2
7.40 / 28
3
9.51 / 36
4
11.62 / 44
5
13.21 / 50
6
15.85 / 60
7
17.96 / 68
F
21.13 / 80
Low fuel indication & buzzer ON at 2 Graduation & OFF at 3rd Graduation. Buzzer sound at the rate of 15 beeps per min. nd
34
6065 / 6075 2WD & 4WD Open Station Rev 01
