MAINTENANCE AND LUBRICATION 277 Cooling System Maintenance The cooling system must be maintained by performing regularly scheduled maintenance as outlined in the Maintenance and Lubrication Manual. Cold weather operations, however, place added demands on the cooling system. Prevent potential cold weather problems by performing a quick check of the cooling system as outlined below: • Make a general check for cooling system leaks. • Inspect hoses and clamps for leaks and condition. Tighten hose clamps to specifications (as required). • Check coolant level. Add fresh coolant (in specified concentration) as necessary. • Check and record degree of antifreeze concentration. Add antifreeze as necessary to obtain required protection level. For additional information concerning the cooling system, refer to the Maintenance and Lubrication Manual (TS494).
Accessory Drive Belt Routing The following diagram shows the accessory drive belt and main belt routing with and without air conditioning. This diagram is located in a clear area on the outside of the left frame between the radiator and center line of the front axle.
C0029647
Accessory and Main Drive Belt Routing 1. Accessory and Main Drive Belt Routing MP7 Engine
