Control and operation
Operating manual
Operating and control elements
Page 1 provides the service life in hours for:
Fig. 3-15
Technical data
Press the Menu button. Page 2 is displayed. The technical data menu, page 2, provides information on :
Press the Menu button again. Page 1 is displayed. To exit the menu: Press the Back button. The submenu will be aborted.
Fig. 3-16
Quantity limitation menu
Page 1 gives information about the operating position of the hydraulic pumps. It gives the following indications for each working pumps : If the flow limitation is activated for the pump. If it occurs, the symbol "R" is dis-
3 - 20
copyright © Liebherr-Mining Equipment Colmar SAS 2021
MJFCIFSS
R 9350 E / 11695771
LEC/en/Edition: 03 / 2021
Status of hydraulic pumps and electrical inputs and outputs menu
