Control and operation
Operating manual
Operating and control elements
E 545
Grease level low
This symbol appears if the grease level drops below minimum level. The bucket will be blocked. Stop operation and stop the motor. Find and correct the problem. Add grease until correct level is reached. See also Lincoln servicing manual.
Information symbols in the INF field Service due This symbol appears if a service interval is due. Switch on the ignition. The service interval to be carried out will be displayed for approx. 10 seconds in place of the overall operating hours. Acknowledge error This symbol appears if a machine error (E 5xx) has occurred and the buzzer sounds simultaneously.
Getting information from the operator’s menu on the main screen Main screen menu selection
Fig. 3-9
Main screen
3 - 16
copyright © Liebherr-Mining Equipment Colmar SAS 2021
MJFCIFSS
LEC/en/Edition: 03 / 2021
Press the Menu button on the main screen. The list of accessible menus is displayed.
R 9350 E / 11695771
