Malfunctions
Operating manual
Fuses and relays
F120
50A
Fuse / air-conditionning
F167
25A
Fuse / elevation pressure fan
F121
50A
Fuse / air-conditionning
F169
15A
Fuse / charging
F122
15A
Fuse / option. windshield wiper F170
F123
50A
Fuse / supply A1020
4.3.2
Reserve
Cabin electrical box E1005 The cabin electrical box E1005
4 - 12
Cabin electrical box E1005
F29
8A
Fuse / reserve cameras
K22_1
Relay / reserve
F30
8A
Fuse / attenu. plate supply res. K22_2
Relay / reserve
F31
15A
Fuse / A1020 boom / shovel tilt K23
Relay second air conditionned
F32
15A
Fuse / A1020 stick / swing
K98
Reserve
F33
15A
Fuse / A1020 / trap door
K99
Relay / supply A1020
F34
15A
Fuse / A1020 FSG
K139
Relay / fire alarm
F35
15A
Fusible / A1020 controller FSG K185
Relay / add. blower heater
F124
15A
Fuse / S7, A1001
K186
Relay / add. blower heater
F125
15A
Fuse / A1019, U16
K191
Relay / preheating hydr. comp.
F126
15A
Fuse / A1001
KT10
Relay timer emergency stop
copyright © Liebherr-Mining Equipment Colmar SAS 2021
MJFCIFSS
R 9350 E / 11695771
LEC/en/Edition: 03 / 2021
Fig. 4-4
