Control and operation
Operating manual
The access and the outfit of the cab
1
Set horizontal, upper
4a Set seat inclination, front
7
Set lumbar support
2
Set horizontal, lower
4b Set seat inclination, rear
8
Seat heating
3
Adjust armrests
6
10 Set backrest
Set lumbar support
This will avoid unexpected movement of the machine.
Setting the armrests
Fig. 3-31
Setting the armrests
Turn the knurled head screw 3 on the armrest in direction a. The armrests incline upwards.
LEC/en/Edition: 03 / 2021
Turn the knurled head screw 3 on the armrest in direction b. The armrests incline downwards.
3 - 34
copyright © Liebherr-Mining Equipment Colmar SAS 2021
MJFCIFSS
R 9350 E / 11695771
