Control and operation
Operating manual
Operating and control elements
1
Field for camera 1 (opposite side)
F1 F1 button (full screen camera 1)
2
Field for camera 2 (counterweight)
F2 F2 button (full screen camera 2) F8 F8 button (return)
System description Monitoring cameras are installed on the excavator as follows in order to extend the posite side of the cab,
Display The inputs from the different cameras are transmitted to the display located on the front right of the cab and divided on the screen as described above (see Fig. 3-24).
Full screen
Full screen display
The input from one camera can be switched to full screen (with the input from the other camera remaining simultaneously displayed with normal size). To switch a camera to full screen: Press F1. Camera 1 is switched to full screen while camera 2 remains displayed with normal size. Press F2.
3 - 26
copyright © Liebherr-Mining Equipment Colmar SAS 2021
MJFCIFSS
R 9350 E / 11695771
LEC/en/Edition: 03 / 2021
Fig. 3-25
