TMS800E OPERATOR’S MANUAL
OPERATING CONTROLS AND PROCEDURES
7.
Remove the hookblock and/or headache ball from the hoist cable(s) and stow securely before traveling or ensure headache ball is properly secured to the tie down provided for that purpose.
8.
Ensure the outrigger stabilizers and outrigger beams are fully retracted and the floats are removed.
9.
Ensure the center front stabilizer is fully retracted. Floats remain installed.
10. Ensure the stabilizer floats are properly stowed in their holding racks.
b.
With the boom over the rear, the counterweight used must be from 5440 kg (12,000 lb) to 8170 kg (18,000 lb).
7.
Swing lock and pin shall be engaged.
8.
Hookblock must be removed from main boom nose.
9.
Headache ball may be reeved over boom extension, hanging 0.9 m (3 feet) below sheave.
10. Suspension air bags shall be inflated. 11. The tires shall be properly inflated.
11. Ensure the cover doors on the outrigger control panels, battery box, and sling box are closed.
10 m (33 ft)/17 m (56 ft) Extension Plus One or Two 6 m (20 ft) Insert(s
12. Close and/or install all superstructure cab windows and door.
Travel is permissible under the following conditions. 1.
Traveling With Boom Extension And/Or Inserts Erected
The 10 m (33 ft) or 17 m (56 ft) boom extension shall be erected at minimum offset. If traveling with just the 10 m (33 ft) extension, the stinger section must be stowed on the boom base section, not on the extension base section.
2.
Jobsite travel only on firm, level surface.
10 m (33 ft)/17 m (56 ft) Extension
3.
Main boom shall be fully retracted.
Travel is permissible under the following conditions.
4.
Main boom angle: 3 degrees minimum, 30 degrees maximum.
5.
Maximum travel speed: 4 km/h (2.5 mph).
6.
With the boom over the front, the counterweight used can be from 0 kg to 8170 kg (18,000 lb) or 10,900 kg (24,000 pounds). Travel with the boom over the rear is not permitted with insert(s) erected.
13. If traveling with 24,000 pounds (10,900 kg) of counterweight installed, maximum travel speed is 2.5 mph. Suspension air bags should be inflated.
1.
The 10 m (33 ft) or 17 m (56 ft) boom extension shall be erected at minimum offset. If traveling with just the 10 m (33 ft) extension, the stinger section must be stowed on the boom base section, not on the extension base section.
3
2.
Jobsite travel only on firm, level surface.
3.
Main boom shall be fully retracted.
7.
Swing lock and pin shall be engaged.
4.
Main boom angle: 3 degrees minimum, 30 degrees maximum.
8.
Auxiliary hoist or IPO counterweight must be installed.
9.
Hookblock must be removed from main boom nose.
5.
Maximum travel speed: 4 km/h (2.5 mph).
6.
Counterweight:
10. Headache ball may be reeved over boom extension, hanging 0.9 m (3 feet) below sheave.
a.
11. Suspension air bags shall be inflated.
With the boom over the front, the counterweight used can be from 0 kg to 8170 kg (18,000 lb) or 10,900 kg (24,000 pounds).
GROVE
12. The tires shall be properly inflated.
Published 12-23-2008, Control # 132-03
3-31
