TMS800E OPERATOR’S MANUAL
OPERATING CONTROLS AND PROCEDURES
is first turned on. If an indicator comes on and continues to blink after initial start-up, there is a problem that needs to be corrected. Check the engine manufacturer’s service manual for further information. 1.
Ensure the parking brake is set and position the transmission in neutral.
NOTE: 2.
3.
The engine will not crank unless the transmission shift is in neutral.
Turn the ignition switch to start (far right position) and release immediately when the engine starts. Do not push or hold the throttle down. The ECM will automatically provide the proper amount of fuel to start the engine. Immediately check the engine instruments for proper indication after starting. Shut down the engine if the oil pressure gauge does not reach the proper reading within 15 seconds.
The engine is equipped with an automatic cold starting system that provides a metered flow of starting fluid to the engine when the engine temperature is 13 °C (55°F) or below. A thermostatically-controlled valve automatically opens to allow starting fluid to the engine. It is recommended that no other type of cold starting aid be used with this engine. An engine block heater is also provided. If starting fluid runs out, replace the empty starting fluid container with a full container.
CAUTION T h e o p t i o n a l e n g i n e c o l d s ta r t s y s t e m o p e r a t e s automatically when the engine temperature is 13°C (55°F) or below. If the engine does not start immediately, avoid overloading the air box with highly volatile fluid which could result in a minor explosion. 1.
Ensure the parking brake is set and position the transmission in neutral.
NOTE:
DANGER Both air system pressures must be in the normal operating range prior to disengaging the park brake.
2.
Turn the ignition switch to start (far right position) and release immediately when the engine starts. Do not push or hold the throttle down. The ECM will automatically provide the proper amount of fuel to start the engine.
3.
Immediately check the engine instruments for proper indication after starting. Shut down the engine if the oil pressure gauge does not reach the proper reading within 15 seconds.
CAUTION If oil pressure and/or temperature indicator(s) do not display the proper readings, shut down engine and correct malfunction. 4.
The engine will not crank unless the transmission shift is in neutral.
Allow the engine to warm up for about five minutes before applying a load. Do not race the engine for a faster warm up.
Cold Engine
DANGER Both air system pressures must be in the normal operating range prior to disengaging the park brake.
DANGER Wear proper eye protection when replacing starting fluid containers. Starting fluid can cause blindness or severe eye damage and breathing problems.
CAUTION Always start a cold engine from the carrier cab.
4.
The engine warning and engine stop indicators will illuminate and go off after about two seconds (as a check) when the key is first turned on. If an indicator comes on and continues to blink after initial start-up, there is a problem that needs to be corrected. Check the engine manufacturer’s service manual for further information.
GROVE
CAUTION If oil pressure and/or temperature indicator(s) do not display the proper readings, shut down engine and correct malfunction. Allow the engine to warm up for about five minutes before applying a load. Do not race the engine for a faster warm up.
Idling The Engine Idling the engine unnecessarily for long periods of time wastes fuel and fouls injector nozzles. Unburned fuel causes carbon formation; oil dilution; formation of lacquer or gummy
Published 12-23-2008, Control # 132-03
3-21
