TMS800E OPERATOR’S MANUAL
OPERATING CONTROLS AND PROCEDURES
Push the very top of the switch to activate the washer switch to spray washer fluid on the windshield.
Headlights Switch The headlights switch (21) is a three position switch located on the bottom left side of the front console. The bottom position is off. The center position will illuminate marker, clearance and gauge lights. The top position will turn on the headlights in addition to the marker, clearance and gauge lights.
Beacon Light Switch (Optional)
Dimmer Switch The dimmer switch (31) is located on the left bottom side of the front console. The switch controls the brightness of the gauge lights. The headlight switch (21) must be in the center or top position before gauge lights will illuminate and the dimmer switch becomes functional.
Headlights Dimmer Switch The headlights dimmer switch (47) is incorporated in the turn signal switch. It is located on the left side of the steering column. The switch is activated by pulling or pushing the turn signal lever toward you or away from you.
Turn Signal Lever The turn signal lever (47) is located on the steering column. Positioning the lever down causes the indicator light on the console and the left front and left rear signals to flash. Positioning the lever up causes the indicator light on the console and the right front and right rear signals to flash.
Cruise Control The cruise control (47) is incorporated in the turn signal lever located on the left side of the steering column. Push the switch to ON to turn the cruise control on. Accelerate to desired speed and push (SET COAST) button on end of lever. If cruise is stopped by braking and switch is still positioned to ON, the switch can be pushed to (RESUME-ACCEL) to resume cruise speed. Position switch to OFF to turn the cruise control off.
Hazard Light Switch The hazard light switch (55) is located on the steering column. Pulling on the switch (in the direction of the arrow) causes all the turn signals and the indicator light on the console to flash.
GROVE
The left turn signal indicator (3) is located on the top left side of the front console. It is a green indicator light that flashes when the turn signal lever or hazard switch is pulled down.
Right Turn Signal Indicator The right turn signal indicator (6) is located on the top right side of the front console. It is a green indicator light that flashes when the turn signal lever or hazard switch is pushed up.
Steering Column Tilt/Telescope Lever
The beacon light switch (19) is a two position, on-off switch located on the left side of the front console that controls the beacon light (42) on the top of the carrier cab.
NOTE:
Left Turn Signal Indicator
The steering column tilt/telescope lever (56) is located on the steering column behind the turn signal lever. Pulling back on the lever allows the steering column to be tilted, and pushing forward on the lever allows the steering column to be telescoped in and out.
Horn Button The horn button (46) is located in the center of the steering wheel (45). Depressing the horn button energizes the circuit sounding the horn.
Fire Extinguisher The fire extinguisher (43) is mounted on the left inside rear of the cab.
Cab Circulating Fan The cab circulating fan (50) is mounted on the left front of the cab and is controlled by a two speed rocker switch on the base of the fan.
Tire Inflation Switch The tire inflation switch (18) is located on the left side of the front console. It is a two position switch that activates the tire inflation system. Push the top of the switch to activate the tire inflation system. An amber indicator will illuminate and the warning buzzer will sound when the switch is in the on position.
12 VDC Accessory Outlet The 12 vdc accessory outlet (9) is located on the right side console. It provides an outlet for the operator to plug in a 12 vdc accessory. This outlet should be used only for components requiring 8 amps or less.
Cab Dome Light (Not Shown) The cab dome light (44) is located in the center of the cab roof directly over the seat. It is controlled by a switch on the light and by a door switch that powers the light when the cab door is opened.
Published 12-23-2008, Control # 132-03
3-7
3
