FUEL TANK abJe solution. Disassemble the fuel shut-off valve and dean it thoroughly. Dry the tank thoroughly, then reassemble the shut-off valve and mount it on the tank.
A. Removal 1. Disconnect the battery ground cable from the right side of the tractor. 2. Remove the hood assembly.
3. Turn the fuel shut-off valve to the "OFF" position. Disconnect the fuel line from the fuel filter. Disconnect the fuel return line from the forward end of the tank.
C. Installation 1. Connect the fuel line to the fuel shut-off valve but do not tighten the line fitting. With an assistant, position the tank on the support brackets making sure the tank front mounting bracket engages the carriage bolt at the fuel tank front support.
4. Place a piece of wood across the top of the battery to prevent the tank from accidentally contacting the post or straps. Remove the bolt and lockwasher that attaches the tank to each side of the fuel tank rear support.
2. Install the two rear attaching bolts. Tighten the front mounting bolt
S. Loosen the nut t hat attaches the fuel tank to the front support.
3. Connect the fuel line to the fuel filter, and tighten both fittings. Connect the fuel return line to the front of the fuel tank.
6. With an assistant, slide the tank back approximately one inch to fre·e it from the front mounting bolt, then lift it from the tractor. Disconnect the fuel line from the tank.
NOTE: Tighten fuel line connections care-
fully. The fittings are brass and it is possible to strip the thrends if they are over-tightened.
B. Cleaning
4. Install the hood assembly.
1. Water caused by normal condensation, accumulates in the fuel tank when aUowed to stand low or empty for a period of time (usuaHy overnight). Therefore, it is a good practice to fill the tank to capacity at the end of each day of operation to prevent moisture laden air from forming water, rust and gum formation. Long periods of tractor storage may also cause gum formations in the tank.
5. Turn the fuel shut-off valve to the "ON" position. Remove the wood from the top of the battery. Connect the battery ground strap to the right side of the tractor. 6. Bleed the fuel system as detailed in Section 3 below.
2. If it is necessary to clean the tank, drain the fuel completely and remove the shut-off valve fitting.
7. Fill the air cleaner oil bath tray to the oil level mark with the specified engine oil. Using a new oil bath tray gasket, secure the tray to the air cleaner.
3. Wash the interior of the tank thoroughly with a mixture of alcohol and acetate or any other suit-
8. Connect the air inlet tube to the air deaner and secure with the hose clamp.
BLEEDING AND FLUSHING THE FUEL SYSTEM en the bleed screw.
A. Bleeding the Fuel Filter
IMPORTANT: iVever open the bleetl screw
1. Open the fuel tank shut-off valve at the bottom of the tank.
when the engine is running as air will be sucked into the system.
2. Open the drain cock at the bottom of the fuel filter base, Figure 4. Close the drain cock when the fuel begins to flow.
B. Flushing the Injectors and Pressure Lines
3. Open the bleed screw at the top of the nlter cover two turns to release any air that may be trapped. After a solid flow of fuel appears, tight~
1. Disconnect the pressure line from each injector. Move the pressure lines %:rYts" away from the injectors.
101
