Claas JAGUAR 900 – 830 JAGUAR 900 – 830 Profistar JAGUAR 900 – 830 Speedstar Repair Manual

Air conditioning Unscrew the air conditioner compressor from the engine.

(Fig. 66)

66

Fitting the compressor 1. Screw the air conditioner compressor to the engine.

In doing this, the hex head bolts must be fitted with a liquid thread sealing compound, e.g.

DELO-ML-5349, (Part no. 0201 801.1), and tightened down. When doing this, observe the relevant tightening torque – see page 1.4.1, Tightening torques screws.

(Fig. 67) 67 2. Screw the air conditioner hoses back onto the compressor at the flange (S), using new round seal rings.

(Fig. 68)

S 68

0298 826.1 - RHB JAGUAR 900 – 830 Profistar / Speedstar

2.3.21
