Air conditioning 4. Air conditioning unit – filling up the refrigerant, see page 2.3.1. 5. Check the function and check for leaks.
Removing the compressor coupling Removing the fan drive belt (10), see page 8.3.1. Removing the compressor drive belt (13), see page 8.3.7. With DaimlerChrysler OM 457 LA (JAGUAR 870 – 830): Unscrew protective sheet (A). (Fig. 40)
A 40 With DaimlerChrysler OM 502 LA (JAGUAR 900 – 890): Unscrew the air conditioner compressor from the engine and lay aside so that fitting work can be carried out in the area of the V-belt pulley. Attention! The air conditioner hoses should not be released or bent over when doing this. 41
(Fig. 41) Turn on the ignition, but do not start the diesel engine. Switch the air conditioning on and set the fan switch to the first position. Unscrew the cover (B). (Fig. 42)
B
42
2.3.14
RHB JAGUAR 900 – 830 Profistar / Speedstar - 0298 826.1
