Air conditioning Unlock the hose (A) on the radiator cage and pull off. Hinge up the radiator cage.
A
(Fig. 36)
36 Unscrew the hose lines (B) from the condenser (C) and close off on both sides with plugs. Unscrew the condenser (C) from the radiator cage. (Fig. 37) B
C
37
Fitting the condenser 1. Screw the condenser (C) to the radiator cage.
B
2. Screw the hose lines (B) to the condenser (C) using new round seal rings. When doing this, observe the relevant tightening torque – see page 1.4.3, Tightening torques hydraulic fittings.
C
(Fig. 38)
38 3. Push the hose (A) onto the spigot on the radiator cage (C) and lock. A
(Fig. 39)
39
