Air conditioning Fitting the temperature switch 1. Insert the capillary tube (K) of the temperature switch (14) through the cab lining, bend over at about 80 mm from the end through 90° and carefully insert into the evaporator (7) at (X and Y).
K
Y X
(X) = 60 mm (Y) = 30 mm 7
Attention! 27
Force should never be used to push in the capillary tube (K) and it should not be bent over. (Fig. 9, 27, 28) 2. Secure the capillary tube (K) with the clamp (E).
K
3. Screw the temperature switch (14) to the shield (D) and push the rotary switch (15) on.
E
(Fig. 9, 28)
14 D 15
28 4. Glue the sealing plate (6) on. 5. Seal the line guide with sealant (B). (Fig. 9, 29) 6
B 29 6. Check the function and check for leaks.
2.3.10
RHB JAGUAR 900 – 830 Profistar / Speedstar - 0298 826.1
