Air conditioning Pull off the sealing plate (6) carefully. Remove the sealing compound (B). (Fig. 9, 23) 6
B 23 Carefully pull the capillary tube (K) out of the evaporator (7).
K
Attention! Force should never be used to remove the capillary tube (K) and it should not be bent over.
7
(Fig. 9, 24) 24 Removing the shield (D). Pull off the plug from the temperature switch (14).
E
Release the clamp (E). Pull off the rotary knob (15), unscrew the temperature switch (14) from the shield (D) and carefully remove the capillary tube (K).
14
(Fig. 9, 25, 26) D
15
25
K
26
0298 826.1 - RHB JAGUAR 900 – 830 Profistar / Speedstar
2.3.9
