Claas JAGUAR 900 – 830 JAGUAR 900 – 830 Profistar JAGUAR 900 – 830 Speedstar Repair Manual

Air conditioning 24

2. Push the suction line (23) and pressure line (24) with new round seal rings (9 and 11) into the expansion valve (10) and screw on the holding plate (B).

B

3. Seal the line guide with sealant (Fig. 9, 19, 20)

23 20 4. Air conditioning unit – filling up the refrigerant, see page 2.3.1.

5. Check the function and check for leaks.

6. Screw the cover (A) to the top of the cab.

(Fig. 21)

A

21

Removing the temperature switch Hinge up the cab roof.

Unscrew the cover (A) from the top of the cab.

(Fig. 22) A

22

2.3.8

RHB JAGUAR 900 – 830 Profistar / Speedstar - 0298 826.1
