Air conditioning Pull off the sealing plate (6) carefully. Remove the sealing compound (B). (Fig. 5, 9) 6
B 5 Carefully pull the capillary tube (K) out of the evaporator (7).
K
Attention! Force should never be used to remove the capillary tube (K) and it should not be bent over.
7
(Fig. 6, 9) 6 Unscrew the holding plate (C). Pull out the suction pipe (23) and the pressure pipe (24) and close the ends off with plugs. 7 24
(Fig. 7, 9)
C
23
7 Remove the holding plate (D). Pull the expansion valve (10) off and seal both connections off on each side using plugs.
10
Pull the evaporator (7) out of the roof of the cab. (Fig. 7, 8, 9)
D 8
0298 826.1 - RHB JAGUAR 900 – 830 Profistar / Speedstar
2.3.3
