Maintenance Quick-change system for mower blades To change the mower blades: 5
– Remove the mounting lever (5) from the bracket. (Fig. 67)
67
– Insert the mounting lever (5) between the cutting disc (6) and the mower blade bracket (3). 6
(Fig. 68)
5
68
68985
NOTE! Pull the mounting lever (5) outwards parallel to the axis of the cutting disc up to the stop. 5
(Fig. 69)
69
68986
– Clean the recess (8) in the skid. – Place the mower blade bracket (9) exactly over the recess (8) by turning the cutting disc. – Push the mounting lever (5) downwards.
5
9 68987
9.33
(Fig. 70)
8 70
