Maintenance Mower blade box There is a mower blade box (1) located on the left hand side of the back panel, in which replacement mower blades can be kept.
1
• Remove the mower blade box (1) from the bracket
2
by releasing the spring (2). (Fig. 62)
62
3 = Stowage space for mower blades 00 0952 043 0 4 = Stowage space for mower blades 00 0952 042 0
3
• Take the box with mower blades (1) to the mower head when replacing mower blades.
4
(Fig. 63, 64)
00 0952 043 0
00 0952 042 0 63
4 3 1
9.31
64
BA DIRECT DISC 610 / 520 Comfort - 00 0294 017 2
